Systemair Save VTR 700 R Rotational Heat Recovery Unit, Right Side, Floor (488834)

Systemair More from Systemair
SKU
269145
Ean
488834
Special Price €5 790,87 was €7 528,12
energy Info sheet
Out of stock
Write a review
Systemair Save VTR 700 R Rotational Heat Recovery Unit, Right Side, Floor (488834)
Shipping methods:
Self-pickup - Ganību dambis 25D |
Receive from 28. November till 6. DecemberSelf-pickup | Not available
CONVENIENT SHOPPING
CONVENIENT SHOPPING
70.000+ PRODUCTS
100.000+
PRODUCTS
DELIVERY ALL OVER LATVIA
DELIVERY ALL OVER LATVIA
CLIENT SUPPORT
CLIENT SUPPORT
More Information
Details
Reviews

More Information

Manufacturer
Systemair
Collection
Save VTR 700 R
Type
Vertikāls
Connection
Labā puse
Air duct diameter (mm)
250mm
Diameter (mm)
20mm
Protection class
IP24
Connection diameter (mm)
250mm
Recommended room area (m²)
550m²
Recommended room area (m²)
550
Air supply side
Labā puse
Location
Sienas, Grīdas
Placement side
Labā puse
Heat exchanger
Rotācijas
Energy efficiency class
A
Productivity (m³/h)
954
Heat recovery %
81
Location
Grīdas/Sienas
Effectiveness
81%
Mounting type
Vertikāls
Power (kw)
1.67kw
Yield m3/h
954m³/h
Height (cm)
121.5
Width (cm)
117
Noise level
41dB
Weight (kg)
188kg
Svītrkods
488834

Details

SAVE VTR 700 is designed for ventilated areas up to 550 m2. Right handed model. SAVE VTR 700 has white painted double skinned panels. The unit is equipped with a high efficiency variable speed rotating heat exchanger and a moisture transfer function that regulates the rotation speed of the rotor. Energy efficient fans with EC motors as well as low-pressure filters reduce the energy consumptions and ensures low SFP factor (Specific Fan Power) and sound level. The built-in humidity sensor in extract air can be used for demand control.

The unit can be operated in a variety of ways:

SAVE LIGHT – control panel for basic functions such as airflow control, general alarm and filter change indication.

SAVE TOUCH – control panel with touch screen and full access to all functions and settings. The home screen displays information such as airflow, temperature, air quality and active functions. You can select between MANUAL and AUTO mode or select preferred settings from the pre-configured user modes and much more.

SAVE CONNECT – Home solutions by Systemair mobile application and Internet Access Module for wireless control of the SAVE unit. The mobile application mirrors functionality of SAVE TOUCH control panel and allows you to access all control functions on your smartphone.

Each control method is optional and have to be ordered separately as an accessory. 6 meter cable for the control panel is included with the unit.

Built-in reheater (water or electric 1.67 kW) is available as an accessory.

External connection board that has prewired inputs and outputs allows easy installation and setup of external sensors as well as external heaters / coolers and other accessories.

Main features:

  • High energy-efficiency rotary heat exchanger with EC technology fans
  • Demand control regulation with the built-in humidity sensor
  • Moisture transfer function to minimize condensation in supply air during wintertime
  • Multiple control options to choose from
  • Connection board for easy access and connection of accessories
  • Modbus communication RS-485 as standard
  • Eurovent Certification
